Echo Power Pruner PPT-300ES

Po w e r Pr u n e r
TM
oP e r a T o r 's Ma n u a l
31
sp e c I f I c a t I o n s
MODEL ---------------------------------------------------- PPT-30ES
Length (Extended) (with cutting attachment) ---------- 4.035 m (13 ft. 2 in.)
Width -------------------------------------------------------- .246 m (9.69 in.)
Height ------------------------------------------------------- .259 m (10.2 in.)
Weight (dry) (with cutting attachment) ----------------- 8.7 kg (19.25 lb.)
Weight (dry) (without cutting attachment) ------------- 8.1 kg (17.85 lb.)
Engine Type ------------------------------------------------ Air cooled, two-stroke, single cylinder gasoline engine
Bore ---------------------------------------------------------- 34.0 mm (1.34 in.)
Stroke -------------------------------------------------------- 31.0 mm (1.22 in.)
Displacement ----------------------------------------------- 28.1 cm
3
(1.71 cu. in.)
Exhaust System -------------------------------------------- Spark arrestor mufer or spark arrestor mufer with catalyst
Carburetor--------------------------------------------------- Diaphragm type
Ignition System -------------------------------------------- Electronic
Spark Plug -------------------------------------------------- NGK BPMR-8Y Gap 0.65 mm (0.026 in.)
Fuel ---------------------------------------------------------- Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio ---------------------------------------------- 50 : 1 (2 %) for ISO-L-EGD Standard (ISO/CD 13738), JASO FC/
FD grade and ECHO Premium 50 : 1 oil.
Petrol -------------------------------------------------------- Regular grade petrol. Minimum 89 Octane unleaded petrol is
recommended. Do not use fuel containing methyl alcohol or more
than 10 % of ethyl alcohol.
Fuel Tank Capacity ---------------------------------------- 62 cm
3
(21.1 US . oz.)
Starter System ---------------------------------------------- Automatic Recoil Starter
Clutch-------------------------------------------------------- Centrifugal Type
Power Transmission Shaft Assembly ------------------- Aluminum Extrusion
Gear Case Ratio -------------------------------------------- 1.53:1
Oiling System ---------------------------------------------- Automatic
Saw Chain Oil Capacity ---------------------------------- 22 cm
3
(7.6 oz.)
Guide Bar and Saw Chain (91) -------------------------- 305 mm (12 in.) .050 gauge, sprocket nose; 9.53 mm 91VX44X
(3/8 in.) pitch, 0.050 gauge
Handle ------------------------------------------------------- Right hand grip w/throttle trigger and lockout
Shoulder Harness ------------------------------------------ Standard
Fuel consumption ------------------------------------------ 0.65 L/h
- Specic fuel cconsumption at maximum engine power - 510 g/Kwh
2006/42/EC
- Vibration Levels (ISO 11680-1)
Values declared front handle/rear handle ------ 4.0 / 4.4 [
+
1.0] m/s
2
- Sound pressure level (ISO 11680-1) LpAeq --------- 93.1 [
+
1.0] dB (A)
- Sound power level (ISO 11680-1) LWAeq ---------- 105 [
+
3.0] dB (A)
2000/14/EC
- Measured Sound power level (ISO 11680-1) LWA -----108 [
+
3.0] dB (A)
- Guaranteed sound power level (ISO 11680-1) LWA ---111 dB (A)
2002/44/EC Vibration: A(8) front handle/rear handle ----1.0 / 1.1 m/s
2
2002/88/EC Emission Directive Stage 2 --------------- listed (engine type S11-2BA)
Maximim shaft brake power ----------------------------- .93 kw
Idle Speed (RPM) ------------------------------------------ 2,500 - 3,000
Clutch Engagement Speed (RPM) ----------------------- 3,800
Wide Open Throttle Speed (RPM) ---------------------- 9,500 - 11,500
-
PPT-300ES
Vibration levels(ISO 11680-1):
Declared values Front handle/ Rear handle
a
hv,eq
m/s
2
4.0 / 4.4 [±1.0]
Sound pressure level (ISO 11680-1)
L
p Aeq
dB (A) 93.1 [±1.0]
2006/42/EC
Sound power level (ISO 11680-1)
L
W Aeq
dB (A) 105 [±3.0]
Measured sound power level(ISO 11680-1)
L
W A
dB (A) 108 [±3.0] 2000/14/EC
Guaranteed sound power level(ISO 11680-1)
L
W A
dB (A) 111
2002/44/EC Vibration: A(8) Front handle / Rear handle m/s
2
1.0 / 1.1
PPF-300ES
Vibration levels(ISO 11680-1):
Declared values Front handle/ Rear handle
a
hv,eq
m/s
2
3.7 / 3.6 [±1.0]
Sound pressure level (ISO 11680-1)
L
p Aeq
dB (A) 91.3 [±1.0]
2006/42/EC
Sound power level (ISO 11680-1)
L
W Aeq
dB (A) 104 [±3.0]
Measured sound power level(ISO 11680-1)
L
W A
dB (A) 107 [±3.0] 2000/14/EC
Guaranteed sound power level(ISO 11680-1)
L
W A
dB (A) 110
2002/44/EC Vibration: A(8) Front handle / Rear handle m/s
2
0.9 / 0.9
-
-
-
