144
Adjusting sound quality
How to operate the unit when an optional 5.1 ch decoder/AV matrix unit connected
Touch or for
FREQUENCY to select the cut off
frequency.
● : Increase cut off frequency
: Decrease cut off frequency
● The following cut off frequencies can
be selected.
Touch to select the
slope.
● Each time is touched, the
slope will be changed in the order
shown below.
● Touch after making
settings. The crossover mode
adjustments will be saved and the
system will return to the previous
operation screen.
Speaker Cut off frequency (Hz)
Front (HI, MID, MID-L)
Center
Rear
100, 125, 160, 200, 250,
315, 400, 500, 630, 800,
1k, 1.25k, 1.6k, 2k, 2.5k,
3.15k, 4k, 5k, 6.3k, 8k,
10k, 12.5k, 16k, 20k
WOOFER
20, 25, 31.5, 40, 50, 63,
80, 100, 125, 160, 200,
250
SLOPE
SLOPE
PASS 6 dB/oct 12 dB/oct
18 dB/oct 24 dB/oct
BACK
