28
Basic operation
Switching audio control modes
Various audio control modes may be fine-tuned using this procedure.
Press the [AUDIO CONTROL] button for less than one
second to select the item to be adjusted.
Modes will switch in the order shown below each time the button is
pressed.
*1
: NON-FADER output does not reflect BASS, MIDDLE, TREBLE,
LOUDNESS and EQUALIZER settings.
*2
: Setting cannot be made in FM mode.
VOL (VOLUME) Mode
Adjusts volume.
Turn the [AUDIO CONTROL] button to the left or right.
Turn to the right: Increases the volume.
Turn to the left: Decreases the volume.
BASS Mode
Adjusts bass level. Bass mode can be adjusted for each source
(CDP/CDC, FM and AM).
Turn the [AUDIO CONTROL] button to the left or right.
Turn to the right: Emphasizes low sounds.
Turn to the left: Softens low sounds.
[AUDIO CONTROL] button
VOL BASS
MID
NON-F *
1
TREB
LOUD
SVC*
2
BAL
FAD
CD5425.book 28 ページ ２００４年１２月１１日 土曜日 午後５時９分
To Next Page
