(36) Press the small right knob to return to the SETUP 2 page after DATA FIELD
CONFIGURATION configuration is set. Press the small right knob again to dismiss
the cursor on SETUP 2.
6. Job Close-Up
SUBTASK AMM-34-50-10-051-A-921-002
A.
Power down the GPS 400W units. Rotate the GPS 400W power knob fully counter-
clockwise past the detent to the off position.
B. Remove all tools, equipment, and unwanted material from work area.
C. If no other work is to be performed, turn off the aircraft power by setting the SYS BATT
and START BATT Switches to the OFF (down) position and BUS TIE to OPEN (down)
position.
D. If no other requirements for External Power, Power down the GPU. Disconnect the GPU
from the aircraft EXTERNAL POWER RECEPTICLE on the aircraft. Disconnect the GPU
from the electrical utility connector.
E. If not previously accomplished, disconnect Weight On Wheels (WOW) box or Aircraft
Maintenance Computer (AMC). Refer to AMM-20-00-04-051-801 – Weight On Wheels
(WOW) Box - Connect/Disconnect.
F. If all other maintenance is complete, return aircraft to service. Refer to
AMM-20-00-02-051-801 – Return To Service (After Maintenance).
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: 0001-0262, POST SB 500-99-005; AND
0266-0267; ALL POST MB 500-31-018
34-50-10
CONFIG A
Page 210
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
To Next Page
