ADS-B - ADJUSTMENT/TEST

AMM-34-50-21-071-801

1. General

This task gives procedures to do the adjustment/test of the ADS-B.

NOTE: ADS-B test is only required, if the ADS-B function is enabled.

• There are two testing setup methods, the preferred method is with the use of a

transponder antenna coupler to limit emissions that may interfere with Air Traffic

Control operations and the second method which uses the IFR-6000 antennas.

2. Equipment and Materials

Special Tools and Equipment

Name and Part Number

Transponder Test Set (Aeroflex, IFR6000) or equivalent

UC-584 Universal Transponder Antenna Coupler | Dual Antenna Kit (Viavi 112349)[1]

Weight-on-Wheels (WOW) Box (EAI, 87-117390-1001) or AMC 2.4.01 (or higher).

Ground Power Unit (GPU). AllStar 450 or AllStar G.S.E. or Hobart GPU-400 or Hobart GPU-

600 or Bycan PS-28100

[1] For test with UC-584 antenna coupler.

3. Job Set-Up with UC-584 Antenna Couplers

SUBTASK AMM-34-50-21-071-921-001-A

Make aircraft safe for maintenance. Refer to AMM-20-00-01-051-801 – Make Safe For

Maintenance.

B. If on jacks, refer to AMM-07-10-00-051-801 – Jacking - Maintenance Practices and

AMM-08-20-00-051-801 – Leveling.

C. Connect external power. Refer to AMM-24-40-00-051-801 – External Power -

Maintenance Practices. Do not turn on START BATT and SYS BATT switches until

prompted.

D. Prepare Anti-ice system for maintenance. Refer to AMM-20-00-03-051-801 – Prepare

Anti-Ice Systems For Maintenance .

E. Connect Antenna Coupler UC-584S to Aircraft upper Transponder Antenna as follows:

(as applicable)

NOTE: For Transponder–1 Adjustment/Test

EA500 Aircraft Maintenance Manual — 06-117751

Temporary Revision No. 34-21

EFFECTIVITY: ALL POST MB 500-31-016

34-50-21

Page 501

Sep 30/20
