H. Connect the coax cable connectors 23K02P03 to the transponder lower antenna relay
coax receptacle marked NO (Normally Open) (4) .
I.
If transponder upper antenna relay installed, connect the coax cable connectors
23K03P03 to the transponder rupper antenna relay coax receptacle marked NO
(Normally Open) (4) .
J. Connect the electrical connector 23K02P04 to the transponder lower antenna relay
electrical receptacle (7) .
K. If transponder upper antenna relay installed, connect the electrical connector 23K03P04
to the transponder upper antenna relay electrical receptacle (7) .
L. Electrically bond the transponder lower antenna relay (1) to the structure. Refer to
AMM-20-03-00-051-801 – Electrical Bonding - Maintenance Practices. Resistance must
be 2.5 milliohms or less.
4.
Job Close-Up
SUBTASK AMM-34-50-23-041-921-002
A.
Remove all tools, equipment, and unwanted material from the work area.
B. If removed, install the air conditioning ducts. Refer to AMM-21-20-11-041-801 – Cockpit
Ducting - Installation.
C. Install the 222 KZ - Multi Function Display (MFD). Refer to AMM-31-10-15-041-801 –
Multi-Function Display - Installation.
D. Remove the warning placards.
E. Do the adjustment/test of the transponder system. Noting effectivity, refer to
AMM-34-50-20-071-801 – Transponder - Adjustment/Test
F. If all other maintenance is complete, return the aircraft to service. Refer to
AMM-20-00-02-051-801 – Return To Service (After Maintenance).
