• ECB - L STATIC HEAT (R FWD Bus)
• ECB - R STATIC HEAT (R FWD Bus)
• ECB - R STATIC HEAT (L FWD Bus)
• ECB - STBY PITOT HEAT (BATT Bus) or ECB - STBY PITOT HEAT (L FWD)
• ECB - L WINDSHIELD HEAT (L AFT Bus)
• ECB - R WINDSHIELD HEAT (R AFT Bus)
(2)
Power down the aircraft by setting the SYS BATT and START BATT switches to OFF
and the BUS TIE switch to OPEN.
(3) Disconnect WOW Box or AMC from aircraft. Refer to AMM-20-00-04-051-801 –
Weight On Wheels (WOW) Box - Connect/Disconnect.
B. Remove the external power from the aircraft. Refer to AMM-24-40-00-051-801 – External
Power - Maintenance Practices.
C. Remove all tools, equipment and unwanted material from work area.
D. If all other maintenance is complete, return aircraft to service. Refer to
AMM-20-00-02-051-801 – Return To Service (After Maintenance).
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: NOTED
34-10-00
Page 532
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
