(22) Verify that the Strike Rate is displayed on the PFDs.
(a)
When Strike Rate reaches approximately 580 ± 40 strikes per minute, verify that
the strikes appear within the required bearing limits for each of the settings on
the WX-PA as shown in Table 503.
NOTE: Strikes may appear approximately at half of the range selected on the
PFD.
NOTE: Press the STRIKE CLEAR LSK after each test.
Table 503. Cardinal Bearings Tests
TEST - 1
• Set WX-PA range = 55 NM
• Set PFD range = 160 NM
Result
(PASS/FAIL)
Set WX-PA bearing = 000° Verify the displayed bearing = 000 ±10°
Set WX-PA bearing = 090° Verify the displayed bearing = 090 ±10°
Set WX-PA bearing = 180° Verify the displayed bearing = 180 ±10°
Set WX-PA bearing = 270° Verify the displayed bearing = 270 ±10°
TEST - 2
• Set WX-PA range = 30 NM
• Set PFD range = 80 NM
Result
(PASS/FAIL)
Set WX-PA bearing = 000° Verify the displayed bearing = 000 ±10°
Set WX-PA bearing = 090° Verify the displayed bearing = 090 ±10°
Set WX-PA bearing = 180° Verify the displayed bearing = 180 ±10°
Set WX-PA bearing = 270° Verify the displayed bearing = 270 ±10°
TEST - 3
• Set WX-PA range = 15 NM
• Set PFD range = 40 NM
Result
(PASS/FAIL)
Set WX-PA bearing = 000° Verify the displayed bearing = 000 ±10°
Set WX-PA bearing = 090° Verify the displayed bearing = 090 ±10°
Set WX-PA bearing = 180° Verify the displayed bearing = 180 ±10°
Set WX-PA bearing = 270° Verify the displayed bearing = 270 ±10°
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: 0001 - 0008, 0010 - 0050, 0052, 0054 -
0267 POST SB 500-31-024
34-40-50
CONFIG B
Page 508
Sep 30/20
