EN
| 28
Specifications
Complete
Generator Set
Length × width × height 633×381×529 mm
Net. Weight 38 kg
Max. Environment temperature 40°C
Max. Operating Altitude 3000 feet
Manufacture year
Generator
Type
AC rated voltage
AC rated current
26.7A (Gasoline)
24.2A (LPG)
Frequency 60Hz
Rated power
Gasoline: 3200W Max. 3500W
LPG: 2900W Max. 3200W
DC output voltage 40V-60V
Rated current 56A
Engine
Engine model EH196i-VE
Engine type
Single cylinder, four-stroke, forced-air
cooling, overhead valve
Engine displacement 196 cc
Type of fuel Unleaded gasoline / LPG
Volume of fuel tank 6 L / 1.59 gal.
Continuous Operation Time (Gasoline) 2.8 H (Nominal load)
Noise Level
(at a distance of 7 meters)
70 dB (Nominal load)
Generator engine oil volume 550 ml / 0.581 quarts
Spark plug model F6RTC
Start mode Electric start
