ECOVACS WINBOT - Accessories and Their Usage; Safety Pod Usage Instructions; Remote Control Operation

ENG - 84
5. ACCESSORIES
5.1 Safety Pod
WARNING
If Winbot is used to clean a window above ground level, the Safety Pod MUST be used.
Winbot must be used in strict accordance with the directions in the Instruction Manual.
ECOVACS is not responsible for any damages due to improper use.
1) Make sure that there is enought power cord for the WINBOT to clean the entire window
without restricting its movement. If there is not enough cord, it is not safe to use the WINBOT
on that particular window until a WINBOT Extension Cord is attached.
2) Loop one end of the Safety Rope around the Safety pod´s channel and pull it tight.
3) Loop the other end of the Safety Rope to the power connector on the power cord and tighten.
4) If an Extension Cord is attached, the Safety Rope must be tied to the power connector on the
Extension Cord. Note: Do NOT attach the Safety Rope to the thin part of the cord.
5) Press the Safety Pod suction cup FIRMLY in the lower corner on the opposite side of the
glass you are cleaning. Make sure the Safety Pod suction cup is securely in place.
6) Place WINBOT on the window, close the window if cleaning the outside of the window, and
start WINBOT.
7) After WINBOT is done cleaning remove it from the window. Grasp the handle, switch the unit
OFF, insert finger into Air Release Trigger and pull up on it for 20 seconds until suction has
dimished.
Please read the entire contents of the Winbot Instruction Manual for detailed instructions.
5.2 Remote Control
Before use of the remote control, please confirm whether the battery has been installed correctly.
• The remote control uses two AAA batteries.
• During installation ofthe battery, be sure to pay attention to the direction of the positive and
negative poles of the battery and the diagram in the Remote Control casing.
• If the battery power is low, replace both batteries; never use a new battery with an old battery.
• lf the remote control is not used for a long time, please remove the batteries so they will not
damage the Remote Control.
• Do not place the remote control in the Sun or next to a heat source as this can damage
the Remote Control.
• Should liquid be spilled on the Remote Control, remove the batteries immediately and shake till
as much of the liquid is out of the Remote Control. Allow to dry for 24 hours before replacing the
batteries. Try to use the Remote with the unit on the window while the unit is within easy reach
to see that it works. If the Remote does NOT work, do not use the unit until the Remote has
been replaced.
• While replacing the battery, should a foreign object be dropped into the battery area, please
remove immediately.
IF the object is left in the battery area, possible shorting of the batteries could happen and ren-
der the Remote Control useless.
• Do not expose remote control directly under sunlight or below strong lighting equipment, othen/
vise it may damage the remote control.
• Please follow the local environmental regulations for the disposal of the discarded batteries.
