BAT-I2 USER MANUAL
12
Chapter 2
1 Remove a blanking plate from the system case corresponding to the slot
you are going to use.
2 Install the edge connector of the add-on card into the expansion slot.
Ensure that the edge connector is correctly seated in the slot.
3 Secure the metal bracket of the card to the system case with a screw.
For some add-on cards, for example graphics adapters and network adapters,
you have to install drivers and software before you can begin using the add-on
card.
Follow these instructions to install an add-on card:
Follow these instructions to install a wireless card or TV tuner card:
1 Insert a wireless card or TV tuner card into the miniPCIE Slot.
2 Lower the handle and tighten the screws.
