BAT-I2 USER MANUAL
Chapter 1
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the BAT-I2 motherboard. This motherboard is a high perfor-
mance, enhanced function. This motherboard has onboard Intel
®
Bay Trail-D J1750/
J1800/J1850/J1900/J2850/J2900 SOC for high-end business or personal desktop mar-
kets.
It supports up to 8 GB of system memory with single channel DDR3 1333MHz
SO-DIMM. It supports one mini PCI Express slot for extending usage (the mini PCIE
supports half-card and you can install a wireless card for it).
It implements an EHCI (Enhanced Host Controller Interface) compliant interface that
provides eight or nine USB 2.0 ports (four USB 2.0 ports at the rear panel and two USB
2.0 headers support additional four USB 2.0 ports and one 5-pin USB 2.0 header
(optional) supports one USB 2.0 port ) and one USB 3.0 port (one USB 3.0 port or one
5-pin USB 2.0 header supports one USB 2.0 port at the rear panel).
The motherboard is equipped with advanced full set of I/O ports in the rear panel,
including one DC_IN port (optional), PS/2 Keyboard & PS/2 Mouse connectors, one
USB 3.0 port(or one 5-pin USB 2.0 header supports one USB 2.0 port), four USB 2.0
ports, one RJ45 LAN connector, one D-sub (VGA) port, one HDMI port and audio jacks
for line-in, line-out and microphone.
In addition, this motherboard supports two SATA 3Gb/s connectors for expansion.
Your motherboard package ships with the following items:
Package Contents
BAT-I2 Motherboard
User Manual
DVD
I/O Shield
2 SATA Cables
Accessories may vary, please refer to actual goods you purchase.
