PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
paremeters for critical voltages, temperatures and fan speeds.
-=- PECI Mode -=-
Offset to TCC Activation Temp : -27
System Temperature : 27°C
CPU Fan Speed : 3214 RPM
System Fan Speed : 0 RPM
CPU Voltage : 1.056V
DIMM Voltage : 1.380V
TCC Activation Temperature (DTS) 35
Smart Fan Function
f
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
PC Health Status
Main Advanced Chipset M.I.B III Security Boot Exit
CPU/System Smart FAN Control (Enabled)
This item allows you to enable or disable the control of the CPU/system fan speed by
changing the fan voltage.
Version 2.02.1205. Copyright (C) 2012, American Megatrends, Inc.
Scroll to this item and press <Enter> to view the following screen:
fSmart Fan Function
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(DTS) 70
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unite
CPU Fan Full Speed Offset (DTS) 77
System Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(DTS) 70
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unite
System Fan Full Speed Offset (DTS) 77
