5
BAT-I2 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. ATX_PWR Standard 24-pin ATX power connector (optional)
2. CPU_FAN 4-pin CPU cooling fan connector
3. CLR_CMOS Clear CMOS jumper
4. DIMM1 204-pin DDR3 SDRAM SO-DIMM
5. CASE Case open header
6. COM1~2 Onboard serial port headers
7. LDC Debug card header
8. LPT Onboard parallel port header
9. SYS_FAN 4-pin system cooling fan connector
10. F_PANEL Front panel switch/LED header
11. DISP_BRT LVDS brightness control header (optional)
12. LVDS LVDS connector (optional)
13. BKLT_PWR Backlight power jumper (optional)
14. LCD_PWR LVDS select jumper (optional)
15. BZ Buzzer
16. MINIPCIE mini PCIE (half card) slot
17. SATA_PWR SATA power connector (optional)
18. F_AUDIO Front panel audio header
19. SATA1~2 Serial ATA 3Gb/s connectors
20. F_USB1~2 Front panel USB 2.0 headers
21. ATX19V 4-pin +19V power connector (optional)
