ECS GF7050VT-M5 User Manual

5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA775 socket for Intel
®
Core
TM
2 Quad*/Core
TM
2
Duo/Pentium
®
D*/Pentium
®
4*/Celeron
®
D CPUs
2. CPU_FAN CPU cooling fan connector
3. DDR2_1~2 240-pin DDR2 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SYS_FAN System cooling fan connector
6. SATA1~4 Serial ATA connectors
7. SPK Speaker header
8. LPT Onboard parallel port header
9. CLR_CMOS Clear CMOS jumper
10. F_PANEL Front panel sw itch/LED header
11. IDE Primary IDE connector
12. FDD Floppy disk drive connector
13. F_USB1~2 Front Panel USB headers
14. USBPWR_F Front Panel USB Power Select Jumper
15. CD_IN Analog audio input header
16. F_AUDIO Front panel audio header
17. PCI1~2 32-bit add-on card slots
18. SPDIFO SPDIF out header
19. PCIEX16 PCI Express slot for graphics interface
20. PCIE PCI Express x1 slot
21. USBPWR_R Real Panel USB PS/2 Pow er Select Jumper
22. ATX12V Auxiliary 4-pin pow er connector
1. CPU Socket

ECS GF7050VT-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Core 2 Duo, Intel Core 2 Quad
CPU fan connector	Yes
Number of SATA connectors	4
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Certification	ROHS
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
BIOS memory size	64 Mbit
Maximum graphics card memory	256 MB
RAID levels	0, 1

Weight and Dimensions

Depth	194 mm
Width	244 mm
