26
Using BIOS
CPU Smart FAN Control (Enabled)
This item allows you to enable or disable the control of the CPU fan speed by
changing the fan voltage.
Version 2.02.1205. Copyright (C) 2012, American Megatrends, Inc.
Scroll to this item and press <Enter> to view the following screen:
fSmart Fan Function
-=- PECI Mode -=-
Offset to TCC Activation Temp : -27
CPU Tct1 : +66
System temperature : +30 C
CPU FAN : N/A
SYS FAN : N/A
CPU Vcore : +1.320 V
VDIMM : +1.560 V
Smart Fan Function
f
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
+/- :Change Opt.
Enter : Select
F1:General Help
lk
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
This item enables you to define the System temperature by smartly adjusting the
System Fan. When it is set at certain temperature, the SYS Fan PWM value will
change accordingly.
SYS Smart Fan Control (Enabled)
Main Advanced Chipset M.I.B III Boot Security Save & Exit
ff
ff
f
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
High Limit Temperature 60
Low Limit Temperature 37
High Limit PWM 200
Low Limit PWM 56
SYS Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
High Limit Temperature 60
Low Limit Temperature 37
High Limit PWM 200
Low Limit PWM 56
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
Enable CPU SmartFan
+/- :Change Opt.
Enter : Select
F1:General Help
lk
mn
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Main Advanced Chipset M.I.B III Boot Security Save & Exit
