ECS HDC-M User Manual

4
Introducing the Motherboard
• AMD Hudson D1 FCH
• Onboard APU AMD
®
Brazos C-60 'ual Core processor with
AMD Radeon
TM
HD 6290 Graphics
• Single-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports 1333(OC)/1066 DDR3 SDRAM
• Supported by AMD Hudson D1 FCH
• 4x Serial ATA 3Gb/s devices
• Realtek ALC662 supports 6-channel HD audio Codec
• Realtek RTL8105E 10/100 LAN (Colay RTL8111-VL Giga
LAN)
• 1 x PS/2 keyboard & mouse connectors
• 1 x DVI port (optional HDMI port)
• 1 x VGA port
• 6 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in, line out)
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
CPU
Specifications
• 2 x PCI slots
• 1 x PCI Express x16 slot (with x4 mode)
Form Factor
• mATX 225mm x 170mm
• AMI BIOS with 32Mb SPI Flash ROM
• Supports ACPI & DMI
• Supports Plug and Play, STR(S3)/STD(S4), Hardware monitor
• Audio, LAN, can be disabled in BIOS
• Supports Dual Display (optional)
System BIOS
Internal I/O
Connectors &
Headers
• 1 x 3-pin SYS_FAN connector
• 1 x 4-pin CPU_FAN connector
• 1 x 24-pin ATX Power Supply connector
• 1 x Speaker header
• 1 x Front panel audio header
• 4 x SATA 3Gb/s connectors
• 1 x SPI_DEBUG header
• 3 x USB 2.0 headers support additional six USB 2.0 ports
• 1 x COM header
• 1 x CASE open header
• 1 x Clear CMOS jumper
• 1 x LPT header
• 1 x TPM header
• 1 x SPDIF Out header
• 1 x Front panel switch/LED header
