ECS HDC-M User Manual

2
Introducing the Motherboard
Feature
The motherboard uses onboard AMD FT1 CPU that carries the following fea-
tures:
Processor
• The AMD FT1 processor combines the central processing unit (CPU)
with the graphics processing unit (GPU) in a single-chip Accelerated
Processing Unit (APU) package.
• The APU connects to the Fusion Controller Hub (FCH) through the
Unified Media Interface (UMI) to provide connections to the different
system devices.
Chipset
Memory
• Supports DDR3 1333(OC)/1066 SDRAM with single-channel archi-
tecture
• Accommodates two unbuffered DIMMs
• Up to 4GB per DIMM with maximum memory size up to 8GB
The AMD Hudson D1 FCH Chipset is a single-chip with proven reliability and
performance.
• PCI slots compliant with PCI Rev 2.2 interface at 33 MHz
• Integrated SATA 3.0 Gb/s Host Controller
• Twelve USB 2.0 ports supported
• Supports
Unified Media interface (UMI), SMBus controller, and High
Definition Audio
• Supports Serial Peripheral Interface (SPI)
• Enhanced DMA Controller, power management, hardware monitoring,
interrupt controller, and clock function.
Onboard LAN (optional)
• Supports PCI Express
TM
1.1
• Integrated 10/100/1000 transceiver
• Integrated Switching Regulator
• Wake-on-LAN and remote wake-up support
• Supports PCI Express
TM
1.1
• Integrated 10/100 transceiver
• Integrated Linear Regulator
• Wake-on-LAN and remote wake-up support
