ECS HDC-M User Manual

1
Introducing the Motherboard
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the HDC-M motherboard of high performance, enhanced
function. This motherboard has an onboard APU AMD
®
Brazos C-60 'ual Core
processor with AMD Radeon
TM
HD 6290 Graphics, design with a Micro-ATX form
factor of 225 x 170 mm.
The motherboard is equipped with advanced full set of I/O ports in the rear panel,
including PS/2 keyboard and mouse connectors, one DVI port (optional HDMI port),
one VGA port, six USB 2.0 ports, one LAN port, and audio jacks for microphone,
line-in and line-out.
The motherboard incorporates the AMD Hudson D1 FCH chipset.
It supports two
PCI slots which are fully compliant to PCI rev 2.2 specification at 33 MHz. One
PCIE16X slot runs at x4 bandwidth which is fully compliant to the PCI Express Base
Specification revision 2.0. This motherboard supports up to 8 GB of system memory
with single channel DDR3 1333(OC)/1066MHz. It implements an
EHCI compliant
interface that provides twelve USB 2.0 ports (six USB 2.0 ports at the rear panel and
three USB 2.0 headers support additional six USB 2.0 ports).
