SE-2003&SE-2012 Series Holter System Recorder User Manual
- 35 -
Gain
5 mm/mV, 10 mm/mV, 20 mm/mV, ±5%
CMRR
≥ 100 dB
A/D Sampling Frequency
25.6 kHz
A/D
24 bits
Minimum Amplitude
50 μVp-p
Resolution
19.53 uV/LSB
Pacemaker Detection
±1 mV ~ ±200 mV, 0.1 ms ~ 2.0 ms
ECG Signal Acquisition
Verification
Through screen of the recorder
Data Transmission
Through USB cable or SD card reader
Input Circuit Current
≤0.1 uA
Time Constant
≥3.2s (0, +20%)
Noise
≤20 uVpp
DC Offset Voltage
±300 mV
Pacemaker Detection
Amplitude
±1 mV to ±200 mV;
When the recorder is in continuous operation at the
sampling frequency of 128 Hz, the amplitude is in the range
of ±2 mV to ±200 mV.
Width
0.1 ms to 2.0 ms
NOTE:
1. Sampling rate and A/D are adapted to default settings before sales.
2. Operation of the equipment below the minimum amplitude may cause inaccurate
results.
