EDAN SONOTRAX Basic - Page 107

SONOTRAX(2009) Series Ultrasonic Pocket Doppler User Manual
99
Acoustic Output Reporting Table for Track 1
Non-scanning Mode
System: SONOTRAX Operating Mode: CW mode
Transducer: CD4.0 Working Frequency: 4.0 MHz
Acoustic Output
MI
I
SPTA.3
(mW/cm
2
)
I
SPPA.3
(W/cm
2
)
Global Maximum Value
0.0125
20.24
0.02024
Associated
Acoustic
Parameter
P
r.3
(MPa)
0.0249
W
0
(mW)
0.746
0.746
f
c
(MHz)
4.0
4.0
4.0
Z
sp
(cm)
0.975
0.975
0.975
Beam
dimensions
X
-6
(cm)
0.142
0.142
Y
-6
(cm)
0.206
0.206
PD
( µ sec)
CW
CW
