SONOTRAX(2009) Series Ultrasonic Pocket Doppler User Manual
21
2.2.3 Buttons
At most there are three push buttons (MODE,
START/STOP and REC/PLAY) and a volume
control button on the main unit of the Doppler. Their
primary functions are as follows:
(1) MODE Button
(Only for SONOTRAX Basic / SONOTRAX
Basic A / SONOTRAX Pro / SONOTRAX II /
SONOTRAX II Pro)
Function: Select the working mode.
(2) START/STOP Button
(Only for SONOTRAX Basic / SONOTRAX Basic
A / SONOTRAX Pro / SONOTRAX II /
SONOTRAX II Pro)
Function: Start/ stop examining (Mode
3)/Change backlight setting (Mode 4).
(3) REC/PLAY
(Only for SONOTRAX Pro/ SONOTRAX II
Pro)
Function: Start/ stop recording or playing fetal
heart sound.
理邦保密文件
EDAN CONFIDENTIAL
