Setting Up the Instrument
Connection Configurations
The Ectane 2 allows various test configurations. The following figures illustrate
some of these configurations.
Figure 1 Typical configuration 1: Ectane 2 with SmartMUX
™
Figure 2 Typical configuration 2: Ectane 2 with SmartMUX, scanner, and probe
ECA
probe
ECA
probe
Scanner/Encoder
