Starting the Instrument
Starting the Instrument
Once you have properly connected all the components of your inspection setup, you
can start the Ectane 2.
1. Connect the power adapter to the power cord.
2. Connect the power adapter to the power socket on the front of the Ectane 2.
3. Connect the power cord to the power outlet.
4. Press the power button until it clicks.
The power button lights up orange and all the indicators on the front panel of
the instrument light up.
Note If you want to use the batteries, simply press the power button.
Understanding Indicators
There are various indicators on the front panel of the Ectane 2. The following
pages explain the various behaviors of these indicators.
Power Indicators
Two indicators are assigned to the instrument’s power status:
Power button indicator
LED integrated in the power button. Lights orange when the Ectane 2 is on.
External power indicator
Lights green when the external AC adapter is connected and powered.
