Inspection Techniques
Inspection Techniques
This section presents the Ectane 2’s operating specifications by inspection
technique.
Eddy Current Testing (ECT)
Probe inputs 8
Number of frequencies 8
Frequency range 5 Hz – 10 MHz
Generator s/ Coil drivers 2
Generator output / Coil drive Up to 20 V, peak-to-peak
Injection modes Multiplexed, simultaneous, continuous
Receiver gain 41 dB range, 23 – 64 dB
Data resolution 16 bits
Acquisition / Sampling rate Up to 50 000 per second
Compatible with external multiplexer Through 41-pin E
XTENDED ET connector
Number of channels
(through external multiplexer)
Up to 64 per ECT frequency
(max. 5 frequencies)
