44
Chapter 5: Specifications Inspection Techniques
Eddy Current Array (ECA)
Remote/Near-Field Testing (RFT / NFT)
Number of channels
Ectane 2 E64 Up to 64 channels for each ECT
frequency (max. 5 frequencies)
Ectane 2 E128 Up to 128 channels for each ECT
frequency (max. 5 frequencies)
Ectane 2 E256 Up to 256 channels for each ECT
frequency (max. 2 frequencies)
or
Up to 128 channels for each ECT
frequency (max. 5 frequencies)
Multiplexer SmartMUX™: integrated, universal,
and programmable
Connector type
a
a. The Ectane 2 uses an ID device found in Eddyfi probes. This ID device contains information that helps set up acquisitions and
confirm compatibility between setup and probe.
Single or double, 160-pin connector
Probe inputs 4 on 19-pin RFT/NFT/MFL connector
8 on 41-pin E
XTENDED ET connector
Number of frequencies 5
Frequency range 5 Hz – 250 kHz
Generators / Coil drivers 2
Generator output / Coil drive 20 V, peak-to-peak
Receiver gain 50 dB range, 36 – 86 dB
Acquisition / Sampling rate Up to 20 000 per second
Connector type 19-pin RFT/NFT/MFL connector
41-pin E
XTENDED ET connector
