24
Chapter 3: Managing Batteries Removing the Batteries
Removing the Batteries
Normally, you can leave the batteries in the Ectane 2 as long as you want.
However, there are times when you must remove them from Ectane 2 (e.g., for
calibration purposes or before placing the instrument on a plane).
To do so:
1. Turn each screw of the battery compartment door counterclockwise a quarter
of a turn.
The battery compartment door pops out.
Figure 2 Opening the battery compartment door
Note The screws are designed to stay with the compartment door.
2. Press down the latch holding the battery in place.
3. Pull the battery tab.
The battery slides out.
Note The battery compartment is designed to hold the batteries firmly. You may need to
use a certain amount of force to pull the batteries out.
