41
General
Environmental Conditions
Housing
Ethernet Cable
Operating temperature
a
a. The Ectane 2 warns you through Magnifi
®
when its operating temperature reaches 65 °C ( 149°F), and then enters power safe
mode to better protect itself when the operating temperature reaches 70 °C (158 °F). In power safe mode, some internal circuitry
shuts down, acquisitions are stopped, and the instrument becomes inactive for work purposes until the condition that initiated the
power safe mode is corrected.
0 °C to 45 °C (32 °F to 113 °F)
Storage temperature –20 °C to 60 °C (–4 °F to 140 °F)
Relative humidity 95%, non-condensing
Pollution degree rating 2
Protection Designed for IP64
Compliance ASME, EN61010-1, EMC, CE, WEEE,
RoHS
Dimensions (W × H × D)
a
a. Outline dimensions include the handle.
279.6 mm × 254.0 mm × 158.8 mm
(11.00 in. × 10.00 in. × 6.25 in.)
Net weight
b
b. Ectane 2 E64 or E128 with batteries.
6.8 kg (15 lb)
Type At least category 5e, shielded
Maximum length 100 m (328 ft)
