eddyfi Ectane 2 User Manual

45
Inspection Techniques
Magnetic Flux Leakage (MFL)
Internal Rotary Inspection System (IRIS)
Probe inputs 4 on 19-pin RFT/NFT/MFL connector
8 on 41-pin E
XTENDED ET connector
Receiver gain 41 dB range, 23 – 64 dB
Connector type 19-pin RFT/NFT/MFL connector
41-pin E
XTENDED ET connector
Number of UT channels 1, pulse-echo
Transducer frequency 5 MHz, 10 MHz, 15 MHz, or 20 MHz
Pulsing rate Up to 30 kHz
Pulser voltage 75 – 200 V (25 V steps)
Pulse width Automatically adjusted for transducer
frequency
Receiver gain 8 – 72 dB (in 1 dB steps)
Receiver DAC Up to 20 dB/µs
RF Filters 4 user-selectable filters for 5 MHz,
10 MHz, 15 MHz, and 20 MHz
transducers
Digitizer 12 bits, 100 MHz
Gates 3; target pin, front wall, back wall
