17
Understanding Indicators
Figure 6 Battery corresponding to battery indicators
Charge level indicators light and blink depending on each battery’s charge level,
as explained below:
LED 1 (from bottom) is blinking Charge is less than 10%
LED 1 is solid Charge is over 10%
LED 2 is solid Charge is over 25%
LED 3 is solid Charge is over 50%
LED 4 is solid Charge is over 75%
