30
Chapter 4: Connector References EXTENDED ET Connector (41 pins)
b Input In2 + input Positive input of input amplifier 2
c Input In2 – input Negative input of input amplifier 2
d Input In3 + input Positive input of input amplifier 3
e Input In3 – input Negative input of input amplifier 3
f Input In4 + input Positive input of input amplifier 4
g Input In4 – input Negative input of input amplifier 4
h – GND Power supply ground to the instrument and casing
i Input In5 + input Positive input of input amplifier 5
j Input In5 – input Negative input of input amplifier 5
k Input In6 + input Positive input of input amplifier 6
m Input In6 – input Negative input of input amplifier 6
n Input In7 + input Positive input of input amplifier 7
p Input In7 – input Negative input of input amplifier 7
q Input In8 + input Positive input of input amplifier 8
r Input In8 – input Negative input of input amplifier 8
s – GND Power supply ground to the instrument and casing
t Output +15 V supply
Motor +
SC +
+15 V supply voltage (1.0 A max.)
Probe motor drive (0–24 V, 2.0 A max., 10 W max.)
Current source (1 A max., 10 W max.)
Table 1 E
XTENDED ET connector pinout (continued)
Pin I/O Signal Description
