32
Chapter 4: Connector References RFT/NFT/MFL Connector (19 pins)
E +15 V supply +15 V supply voltage, 1.0 A max.
F Output Drive2_OUT Coil driver #2 output
G– GND Ground
H Output Drive1_OUT Coil driver #1 output
J –15 V supply –15 V supply voltage, 1.0 A max.
K Input RFT_IN 2+
MFL_IN 2+
Positive RFT input #2
Positive MFL input #2
L Input RFT_IN 2-
MFL_IN 2-
Negative RFT input #2
Negative MFL input #2
M Input RFT_IN 1+
MFL_IN 1+
Positive RFT input #1
Positive MFL input #1
N Input RFT_IN 1-
MFL_IN 1-
Negative RFT input #1
Negative MFL input #1
P Input RFT_IN 4+
MFL_IN 4+
Positive RFT input #4
Positive MFL input #4
R– GND Ground
S Input Identification Probe identification
T – NC No connection
U – GND Ground
V– GND Ground
Table 2
RFT/NFT/MFL connector pinout (continued)
Pin I/O Signal Description
