2 Installation Overview
This chapter includes these sections:
◆ “Package Contents” on page 16
◆ “Switch Installation Tasks” on page 17
Package Contents
After unpacking the switch, check the contents to be sure you have received all the
components.
◆ ECS2100-10T, ECS2100-10P, ECS2100-10PE, ECS2100-28T, ECS2100-28P,
ECS2100-28PP, ECS2100-52T Web-Smart Pro Gigabit Ethernet Switch or
ECS2110-26T Web-Smart Pro 10G Ethernet Switch
◆ AC Power Cord—either US, Continental Europe or UK
◆ Rack Mounting Kit containing two standard brackets and eight screws for
attaching the brackets to the switch.
◆ Power adapter (ECS2100-10PE only)
◆ 4 adhesive foot pads
◆ Quick Start Guide
◆ Regulatory and Safety Information
Optional Item
◆ Console cable—RJ-45 to DB-9
Note:
For other documentations include Installation Guide, Web Management
Guide, and CLI Reference Guide can be obtained from www.edge-core.com ->
support -> download.
