5 Port Connections
This chapter focuses on making connections to switch network interfaces,
including how to install optional transceivers, and details on network cable
specifications.
This chapter includes these sections:
◆ “Cable Labeling and Connection Records” on page 35
◆ “Understanding the Port Status LEDs” on page 36
◆ “How to Install an SFP/SFP+ Transceiver” on page 37
◆ “How to Connect to Twisted-Pair Copper Ports” on page 38
◆ “How to Connect to SFP/SFP+ Fiber Optic Ports” on page 42
◆ “Making 10 Gbps DAC Connections” on page 45
