C SPECIFICATIONS
PHYSICAL CHARACTERISTICS
PORTS
8 10/100BASE-TX, with auto-negotiation
2 10/100/1000BASE-T, shared with two SFP transceiver slots
NETWORK INTERFACE
Ports 1-10: RJ-45 connector, auto MDI/X
10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
1000BASE-T: RJ-45 (100-ohm, UTP or STP cable; Category 5, 5e or 6)
*Maximum Cable Length - 100 m (328 ft)
BUFFER ARCHITECTURE
4 Mbit packet buffer
AGGREGATE BANDWIDTH
5.6 Gbps
SWITCHING DATABASE
8K MAC address entries
LEDS
System: Power, DIAG (Diagnostic),
Port:
status (link, speed, and activity)
