Basic connections and MIDI flow
fig.connect-midi
* Use only the specified expression pedal (EV-5; sold separately). By connecting any other expression pedals, you
risk causing malfunction and/or damage to the unit.
fig.flow-midi-e
When using a MIDI connection
—Transmitting MIDI messages to an external MIDI sound module, etc.
Basic connections
MIDI flow
PC-50 KEYBOARD
The messages of the keyboard, Pitch Bend/Modulation Lever, and VALUE encoder will be
transmitted from here.
MIDI sound module (sold separately)
AC adaptor (sold separately)
MIDI
IN
DP series
(sold separately)
EV-5
(sold separately)
Roland
MIDI OUT
PC-50
PC-50 KEYBOARD
