Three beeps will be heard and then the numbers will be displayed. When finished, the
first digit of the first number will be displayed. If no buttons are pressed within 10
seconds then the mode will be exited automatically or you can press the AWAY button
to exit at any time.
NOTE:
When viewing the numbers via the console note that a 9 is represented by the fault
indicator. A zero in the phone number is represented by the fault and zone 1 indicators.
The end of the number is represented by the fault and zone 4 indicators.
Dialling Function
When the
Solution-8
is triggered, it will commence dialling the first programmed
phone number. If a busy or engaged tone is detected then the panel will hang up and
commence dialling the second number, if there is one programmed.
The first call will however be counted as 1 unsuccessful dialling attempt. A maximum
of 6 calls per alarm event will be made. This count includes any unsuccessful calls and
will reset if the zone re-triggers causing a further 6 attempts to be made.
The control panel will automatically stop calling after 6 attempts or 3 successful calls.
If busy tone is not detected then the panel will assume that the phone has been answered
and will begin sending its transmission.
The transmission consists of a siren tone followed by a unit identification beep. The
identification beep will allow the customer to verify which panel has made the call if
more than one panel is reporting to the same phone number. For example your home
and office could be reporting to your holiday house.
Once the call has been received, if it is not acknowledged using an EDM call
acknowledger, (Part Number CC911) then the panel will continue sending its
transmission for a period of 2 minutes, after which it will hang up and commence
dialling the next phone number. If the call is acknowledged then the control panel will
hang up and no further calls will be made for that alarm.
If the panel is not programmed for upload/download then it is possible to interrogate it
after the call has been acknowledged.
To do this, simply call the phone number that the panel is connected to. The control
panel will answer the call after the pre-pre-programmed ring count has elapsed. A siren
tone will again be heard as well as an alarm type indication beep. The alarm type beeps
will indicate whether a burglary or 24 Hour alarm has occurred.
