Solution-8 Operators Manual Page 7
MA800O3C.DOC
El
ectronics Design & Manufacturing
Mains Indicator
The MAINS indicator is used to indicate that the system mains power is normal or has
failed.
Indication Definition
Flashing Power Failure
On Power Normal
Fault Indicator
The FAULT indicator is used to indicate that the system has detected a battery fault and
that you should contact your installer.
There are however some modes of operation such as changing a user code where the
FAULT indicator is used to represent the digit '9'. This should not be considered as a
fault but interpreted as intended, according to the current mode of operation.
Indication Definition
Off System Normal
On System Failure or displaying the digit '9' during programming
Audible Indications
In general the audible indicators given out by the console are as follows.
Indication Definition
One short beep Indicates that there has been a button pressed or that there
is a Mains failure.
Two short beeps Indicates that the system has accepted your code.
Three short beeps Indicates that the requested function has been executed.
One long beep Indicates end of exit time or that the requested operation
has been denied or aborted.
One short beep / second Indicates that you are currently in the walk test mode.
One short beep / minute Indicates that a mains failure exists, this will coincide
with a flashing mains indicator.
