Page 6 Solution-8 Operators Manual
Electronics Design & Manufacturing
M
A800O3C.DOC
Controls & Indicators
The Console
The console is the communications interface between you and your alarm system. It
allows you to issue commands and offers both visual and audible indications that guide
you through the general operation.
Visual Indicators
The console incorporates twelve indicators. Eight of which are used to indicate the
condition of each zone and four for general status. The following is a list of situations
and the relevant indications that will be seen.
Zone Indicator
Indication Definition
Off Zone Sealed
On Zone Unsealed
Flashing Fast Zone Alarm Condition
Flashing Slow Zone Isolated
Away Indicator
The AWAY indicator is used to inform you that the system is in the armed condition.
Indication Definition
Off System is not in the Away mode
On System Armed in the Away mode
Flashing System in code change mode awaiting command
Stay Indicator
The STAY indicator is used to indicate that the system is armed in the Stay mode.
Indication Definition
Off System is not in the Stay mode
On System Armed in the Stay mode
Flashing System in Isolate mode awaiting
command
