EDMI ES-12B - Page 20

ES-12B 5 Terminal Single Phase Residential Electricity
Meter - Installation and Commissioning Guide
Copyright © 2020 EDMI Europe Ltd. All rights reserved
Version / Status: 1.0
Public
PAGE 20 OF 25
Message
Description
The response message has been sent, the response of which is
indicated by a P (pass) or F (fail). This result is stored in the
commissioning log.
After the command message timeout limit has been reached. The
screen displays the OK TO END prompt. Press OK and then press
OK again, to confirm.
At any stage in the commissioning process, you can use the up/down arrow keys to scroll through
the processed commands, providing a useful checklist to confirm all commands required have
been performed.
Holding the OK button for one second at any stage in the process dismisses the commissioning
mode UI updates.
C
O
M
I
S
4
F
1.
1
C
O
M
I
S
4
P
1.
1
O
K
T
O
C
O
N
F
I
R
M
O
K
T
O
E
N
D
