A708-01-880 Issue E
Page 14 © Edwards Limited 2013. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.3 Mechanical data
Tab le 3 - M ec ha ni c a l D at a
2.4 Electrical data
Note: The CDX temperature sensor and oil pressure sensors are safety-critical devices for ATEX systems. If
applicable, refer to the ATEX system instruction manual for details.
Tab le 4 - El e ct ri c al D at a
Dimensions See Figures 4, 5 and 6
CDX1000 mass (maximum)
30 kW, 50 Hz, Flameproof with Flame Arrestors
40 h.p., 60 Hz, Flameproof with Flame Arrestors
30 kW, 50 Hz, Flameproof
40 h.p., 60 Hz, Flameproof
Pump and motor
1810 kg (3985 lb)
1805 kg (3965 lb)
1710 kg (3765 lb)
1705 kg (3745 lb)
Motor only
310 kg (685 lb)
305 kg (665 lb)
310 kg (685 lb)
305 kg (665 lb)
IDX1000 mass (maximum)
22 kW, 50 Hz, Safe Area
30 h.p., 60 Hz, Safe Area
30 kW, 50 Hz, Safe Area
40 h.p., 60 Hz, Safe Area
IDX1300 30 kW Safe Area
IDX1300 40 h.p. Safe Area
Pump and motor
1575 kg (3460 lb)
1630 kg (3585 lb)
1640 kg (3610 lb)
1705 kg (3745 lb)
1640 kg (3610 lb)
1705 kg (3745 lb)
Motor only
175 kg (380 lb)
230 kg (505 lb)
240 kg (530 lb)
305 kg (665 lb)
240 kg (530 lb)
305 kg (665 lb)
Cleaning solution required to flood the pump cavities
(see Section 5.9)40 l (10.56 US gal)
Nominal electrical supply
Voltage tolerance
Full load current
No load current
Refer to the motor manual supplied with the pump
Refer to the motor manual supplied with the pump
Refer to the motor manual supplied with the pump
Refer to the motor manual supplied with the pump
Starting current/time
Recommended electrical supply cable size
Refer to the motor manual supplied with the pump
Refer to the motor manual supplied with the pump
Te m p e r a t u r e s e n s o r a n d oi l p r e s s u r e se n s o r s
(CDX only: see note above)
Supply voltage
Signal current
24 V d.c.
4 to 20 mA
Thermal snap-switches (IDX only) contact ratings
Maximum voltage
Maximum current (resistive load)
24 V a.c./d.c.
2 A
