Installation
A708-01-880 Issue E
CAUTION
The maximum back pressure (absolute) for the IDX1300 is 15.2 psi.
Tab le 14 - M i n i mu m Pu mp Op erating Temperatures (°F)
Cooling water
temperature
Minimum
operating
temperatures
#
Back pressure (absolute)
14.5 psi 15.2 psi 16.0 psi 16.7 psi
40
Case * 142 144 145 147
Oil
†
171 174 176 178
50
Case * 145 149 151 153
Oil
†
176 189 181 183
60
Case * 149 153 156 158
Oil
†
181 185 187 189
70
Case * 154 158 162 163
Oil
†
185 189 190 192
75
Case * 162 165 169 171
Oil
†
190 194 198 199
85
Case * 169 172 176
178
Oil
†
196 199 203 207
95
Case * 174
178 181 185
Oil
†
201 205 208 212
#With TCV set to 0.
* Case (water jacket) temperature.
†End cover/gearbox (oil) temperature.
Note: A nitrogen shaft-seals purge is required at the operating temperatures/conditions in the shaded cells above.
