Technical data
2.11 Materials of construction
Note: A Material Safety Data Sheet for Fluoroelastomer (Viton) is available on request.
Tab le 1 1 - C o ns tr uc ti o n Ma te r ia ls
Figure 4 - IDX1000 Dimensions: mm (inch) (key)
A. Side view
B. Plan view
C. End view
D. Front fixing dimensions with mounting feet removed
1. Pump inlet
2. Pump outlet
3. Fixing-holes: Ø18 mm (0.71 inch), 2 holes on each mounting foot
4. Fixing-holes: Ø17 mm (0.67 inch), 2 holes on each mounting bracket
Component Material(s)
Stators and W/C plates
Rotors
Gear/end covers
Inlet flange and exhaust manifold
SG iron
SG iron
SG iron
SG iron
Coupling cover
Bearings, gears and oil pumps
Layshaft
Heat exchanger
Oil coolers and pipelines
Grey iron
Steel
Steel
Aluminium/copper
Stainless steel
Coolant pump
Hoses
Hose fittings
SG iron/PPS/Neodymium magnets
Rubber
Brass/iron
Seals purge pipelines and fittings
Shaft seals
O-rings
Stainless steel
PTFE (polytetrafluoroethylene)
Fluoroelastomer (Viton)
Flame arrestor housings
Flame arrestor elements
SG iron
Stainless steel
