Edwards E2M18 User Manual

Figure 11 Remove/replace the inlet lter
CS/1121/A
1
2
3
4
1. Inlet adaptor 2. O-ring
3. Circlip 4. Inlet-lter
1. Inlet adaptor 2. O-ring
3. Circlip 4. Inlet-lter
6.6 Clean the gas-ballast lter
Note:
The gas-ballast lter may have been removed to connect a gas supply or valve to the
gas-ballast inlet.
Refer to Figure: Remove/replace the gas-ballast lter on page 40.
1. Remove the retainer circlip.
2. Remove the protecve wire mesh and lter elements.
3.
Wash the wire mesh and lter in a suitable cleaning soluon. Allow the wire mesh
and lter to dry before replacing them in the pump.
4.
Ret the wire mesh and lter element in the adaptor plate housing and retain with
the retainer circlip.
Page 39
A34310880_T - Maintenance
