Edwards HV30000 User Manual

A313-01-880 Issue A
Page 8 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.4 Cooling-water supply
2.5 Mechanical data
2.6 Lubrication data
Maximum continuous pressure rise (between
pump inlet and outlet) at an inlet pressure not
exceeding 5 mbar
29 mbar
2900 Pa
0.42 psi
24 mbar
2400 Pa
0.35 psi
NA
*
NA
*
NA
*
Maximum motor power 55 kW
75 hp
55 kW
75 hp
55 kW
75 hp
Maximum continuous inlet gas temperature 60 °C
140 °F
60 °C
140 °F
60 °C
140 °F
Maximum continuous outlet gas temperature 120 °C
250 °F
120 °C
250 °F
NA*
NA*
*
Not applicable to the HV40000 which is designed to be operated with inverter control of the motor.
†
On a pump used with DoL (Direct On Line) starting, this is the critical backing pressure at which the pump
must be shut down (see Section 2.2). This is not applicable to pumps operated with inverters (See
Section 1.2).
Table 3 - Cooling-water supply data
Maximum supply pressure 5 bar gauge, 5 x 10
5
Pa, 73 psi
Maximum supply temperature 30 °C, 85 °F
Minimum cooling-water supply through the exhaust gas heat exchanger 30 l min
-1
, 7.92 US gal min
-1
at 30°C
Minimum cooling-water flow rate in series through the two end cover oil
cooling coils
30 l min
-1
, 7.92 US gal min
-1
at 30°C
Table 4 - Mechanical data
Dimensions See Figure 3
Mass Bareshaft With motor mounting kit (but excluding motor)
HV30000 2880 kg, 6350 lb 3017 kg, 6650 lb
HV40000 3260 kg, 7185 lb 3400 kg, 7495 lb
Table 5 - Lubrication data
Recommended oil Royal Purple “Synfilm” GT 220
Oil capacities Shaft-seals oil reservoir Drive end cover Non-drive end cover
HV30000 and HV40000 0.128 litres, 4.33 US oz 6.0 litres, 1.60 US gal 24 litres, 6.34 US gal
Table 2 - Performance data: safe area HV pumps (continued)
HV30000 (50 Hz) HV30000 (60 Hz) HV40000 (60 Hz)
