A313-01-880 Issue A
Page 10 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.10 Materials of construction
2.11 Item numbers
Table 8 - Construction materials data
Oil box cooling coils Copper
Exhaust gas heat exchanger Stainless steel
Stator, headplates, gearbox and end covers Grey cast iron
Rotor SG (ductile) iron
Shaft Carbon steel
Bearings 100Cr6 steel
Shaft seals PTFE
O-ring seal Flouroelastomer
Table 9 - Item numbers
Product description Part No.
HV30000 bareshaft A31301985
HV40000 A31401985
Accessories Order No.
Motor mounting kit for IEC 30 kW motor A31301002
Motor mounting kit for NEMA 40 hp motor A31301006
Motor mounting kit for IEC 55 kW motor A31302002
Motor mounting kit for NEMA 75 hp motor A31302006
