Technical data
A313-01-880 Issue A
2.7 Electrical data
HV 30000 pumps are not supplied fitted with motors. Refer to the Motor Instruction Manual supplied with your motor
and to the motor rating plate and terminal box for details of the electrical supply voltage and frequency, of the full
load current rating, and of the connection procedures for the motor to be fitted to your HV pump.
Ensure that the electrical installation of your HV pump conforms with your local and national safety requirements,
refer to Section 3.8.
2.8 Connections
2.9 Noise and vibration data
Table 6 - Connections data
Process inlet DN500 PN6, 645 mm OD with 20 x 22 mm diameter holes equispaced on
600 mm PCD
outlet ISO 320, 645 mm OD with 12 x M12 tapped holes equispaced on 395 mm
PCD
Cooling-water inlet/outlet, both oil cooler
and exhaust gas heat exchanger
3/8 inch BSP female connection
The noise and vibration data values given below are maximum values for the booster in isolation.
The actual values will depend on the installation and the operating conditions. As these pumps are
used in a system and not in isolation, it is recommended that the user carry out an assessment to
determine if and what Personal Protection Equipment (PPE) may be required.
Table 7 - Noise and vibration data
HV30000 and HV40000
Noise level 83 dB(A)
Vibration level 4 mm s
-1
0.16 inch s
-1
