Edwards iH1000 User Manual

© Edwards Limited 2008. All rights reserved. Page 7
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
A590-00-880 Issue D
2Technical data
2.1 General technical data
Table 1 - Technical data iH80, iH600 and iH1000
Type Characteristics iH80 iH600 iH1000 Units
General Dimensions (L (to exhaust enclosure)
x W x H (to inverter))
*
*
Refer to Web for installation drawings.
776 (909) x
390 x 529
776 (909) x
390 x 839
776 (909) x
390 x 839
(992)
mm
Mass (excluding packaging) 240 415 430 kg
Noise level (ultimate) < 64 < 67 < 69 dB(A)
Vibration level at inlet < 1.8 < 1.8 < 1.8 mm s
-1
Initial force to push the pump 8 16 20 kg
Sustained force to push the pump 5 7 8 kg
Earth leakage <1.1 <1.1 <3 mA
Warm up time to nominal pumping
performance
15 15 15 minutes
Minimum warm up time to process
gas pumping
444hours
Performance
50 Hz / 60 Hz
Typical peak pumping speed 86 / 103 518 / 600 950 / 1000 m
3
h
-1
Ultimate (shaft seal purge only) 3 x 10
-2
/
1 x 10
-2
2 x 10
-3
/
7 x 10
-4
2 x 10
-3
/
1 x 10
-3
mbar
Maximum inlet pressure Atmospheric Atmospheric Atmospheric
Maximum operating time at
maximum inlet pressure
Continuous 1 Continuous hour
Water cooling
system
Minimum flow rate required 2 4 4 l min
-1
Typical heat removed from the
system
2.5 3.2 3.2 kW
Connections Pump inlet flange (bolted) ISO63 ISO100 ISO100
Exhaust gas outlet NW40 NW40 NW40
Extraction port 105 105 105 mm dia
