iXL Dry Pumping Systems
AS
XXXXXXXX0
0
Where r = reserved for future use
Booster Size
Low V
o
ltage
0 = None
1 = r
2 = r
3 = r
4 = 1800
5 = 3000
High V
o
ltage
A = None
B = r
C = r
D = r
E = 1800
F = 3000
TMS System
0 = Standard
1 = r
Exhaust
0 = r
1 = Standard
without
check valve.
2 = r
3 = r
Seals
0 = r
1 = r
2 = Standard
3 = EES
Pump
Motor
0 = None
1 = 4.5 kW
2 = 7.5 kW
3 = 11 kW
Booster
Motor
0 = None
1 = r
2= 4.5 kW
3 = 7.5 kW
4 = r
Gas Module
0 = None
1 = Loadlock (4 slm flow
)
2 = r
3 = r
4 = r
Dry Pump
0 = None
1 = r
2 = r
3 = 250
4 = r
5 = 500
6 = 750
2
4
Table of Contents
Default Chapter
9
Table of Contents
9
Introduction
13
Scope and Definitions
13
Applications
14
Description
14
Priority of Control
14
Active Utility Control
15
The Front Panel Controls
15
Front View of Pumping System
15
The Controls/Connectors on the Rear of the Pump
16
Technical Data
17
General Technical Data
17
General Technical Data
18
Performance Data
19
Loading Data
20
Loading Data (Refer to Figure 5)
20
Nitrogen Purge Data
21
Centre of Gravity and Levelling Foot Loads
21
Nitrogen Purge Data for Ixh and Ixl Systems
21
Gas Module Types and Flows
22
Electrical Data
23
Electrical Data Ixh100 to Ixh1820/H/T
23
General Electrical Data
26
Electrical Connections
27
Wire Assembly According to VDE 0295
28
Cooling-Water Data
29
Water Cooling System Data
29
Cooling Water Supply Temperature
30
Water Consumption Data
31
T Variants
32
Tracer Gas Analysis
32
Heater Data
32
Tracer Gas Test Parameters
32
Tracer Gas Test System Parameters
32
Worst Case Test Results
33
Extraction Rates Required by System Variant
34
Installation
35
Locate the Dry Pumping System
36
Lubrication
37
Connect the Dry Pumping System to Your Vacuum/Exhaust System
37
Reduce the Effective System Footprint
37
Connect to Your Factory Extraction System (Optional)
39
Connecting the Pump Inlet
39
Connect the Nitrogen Supply
40
Flammable/Pyrophoric Materials
40
Gas Purges
41
Leak-Test the System
41
Electrical Supply
41
Mains Supply Cable Connection
43
The Harting Han ® K 4/4 Cable-Mounted Connector
44
The Harting 100A Axial Screw Module Cable-Mounted Connector
45
Customer Connection Kit - Combination Low Volts Ixl750
46
Connect an Additional RF Earth (Ground) (Optional)
47
Connect to Your Emergency Stop Circuit
47
Electrical Connector Locking Mechanism
47
Connect and Set up the Cooling-Water
48
Accessories
49
Commission the System
49
Install Additional Safety Equipment
50
Operation
51
Start-Up
51
Microtim Operation
52
PDT Operation
52
Front Panel Control Operation
52
Status Indicators
52
Manual Shut-Down
53
Shut-Down Modes
53
Microtim Operation
53
PDT Operation
53
Front Panel Control Operation
53
Automatic Shut-Down
54
Alarm Actions
54
Unplanned Shut-Down and Alarms
55
Pump Protection Sensors
55
Emergency Stop
56
Restart the Pump after an Emergency Stop or Automatic Shut-Down
56
Advanced Control and Monitoring
56
Maintenance
57
Safety and Maintenance Frequency
57
Relocate the System for Maintenance
58
Draining the Cooling Water
59
General Maintenance
60
Inspect the Connections, Pipelines, Cables and Fittings
60
Gas Module Configuration
61
Ixh Single Mode and Single Mode
61
Multi Mode
61
Ixl Variants
62
System Operating Temperature Configuration
62
Dry Pump and Booster Temperature Settings
62
Transportation, Storage and Disposal
63
Transportation
63
Storage
63
Disposal
63
Service, Spares and Accessories
65
Introduction
65
Service
65
Ordering Accessories
66
Accessories
66
Seismic Bracket Kits
67
Exhaust Check Valve Kits
67
Appendix A1 Pump Display Terminal
69
A1.1 Leds
69
A1.2 Pump Start / Stop and Control
69
A1 Pump Display Terminal
69
A1 Pump Start Control
69
A1.3 Warning / Alarm Display and Acknowledgement
70
A1.4 Menus
70
A1.4.1 Normal Menu
70
A2 Pump Stop and Control
70
Normal Menu
70
A1.4.2 Status Menu
71
A4 Normal Menu
71
Status Menu
71
A1.4.3 SETUP Menu
72
SETUP Menu
72
A1.4.4 COMMANDS Menu
73
A1.4.5 INV FAULT HIST (Display Inverter Fault History) Menu
73
COMMANDS Menu
73
A8 GAS VALVES Menu
73
INV FAULT HIST (Display Inverter Fault History) Menu
73
A1.4.6 SOFTWARE VERSION Display Menu
74
A1.4.7 FIT ACCESSORY Menu
74
A1.4.8 IP Configuration Menu
74
FIT ACCESSORY Menu
74
IP Configuration Menu
74
A1.4.9 Display Attributes Menu
75
Display Attributes Menu
75
SELECT LINE (Normal Display Selection Menu)
75
UNITS (Units to Display)
75
Appendix A2 Troubleshooting
77
A2.1 Warnings
77
A2.1.1 LED Warning Indicators
77
A2.1.2 PDT Warnings
77
Warnings
77
A2.2 Alarms
80
A2.2.1 LED Alarm Indicators
80
A2.2.2 PDT Alarms
80
Alarms
80
A2.3 Inverter Warnings and Alarms
82
A17 Hexadecimal to Digital Conversion
82
A18 Inverter Alarm Codes
83
A19 Inverter Warnings Codes
84
A20 Inverter Diagnostic Display Text
85
A2.4 Other Problems
87
A2.4.1 Pump Controller Communications
87
