Edwards iXM Series User Manual

Descripon Typical display
Dry pump stator reference temperature TCS REF 100 °C
Dry pump temperature DP TEMP 100 °C
Dry pump exhaust stage temperature DP EXH STG 100 °C
Dry pump end cover temperature DP EC TEMP 100 °C
Dry pump motor temperature DP MTR TEMP 100 °C
Booster temperature MB TEMP 100 °C
Booster motor temperature
MB MTR TEMP
*
100 °C
Booster end cover temperature MB EC TEMP 100 °C
Dry pump power DP POWER 1.1 kW
Booster power MB POWER 1.1 kW
N
2
ow r
ate N
2
FLOW 44 slm
N
2
purge supply N
2
SUPPLY OK
Dr
y pump speed in percent DP SPEED 100%
Dry pump speed in Hz DP SPEED 100 Hz
Booster speed in percent MB SPEED 100%
Booster speed in Hz MB SPEED 100 Hz
Dry pump inverter temperature DP INV TEMP 100 °C
Booster inverter temperature MB INV TEMP 100 °C
Dry pump exhaust pressure EXHAUST 5 PSI
Dry pump exhaust temperature EXH PIPE 100 °C
Dry pump exhaust gas temperature EXH TEMP 100 °C
Acve gauge pressure A
G 1.1E-3 kPa
Water ow rate WATER 11.1 l/m
Run hours RUN HOURS 1000
Number of pump starts PUMP STARTS 100
Time to stop (seconds) TIME TO STOP 900
Acve alarms and warnings (if present)
* In case of TX variants, booster temperature is displayed.
Setup menu
1. Press the Setup buon to enter the menu. Menu tle is shown at the top of the
display. Press up/down keys to scroll.
2. Press ENTER to open a sub menu or CANCEL to return to Normal menu.
Table 22
Setup menu
Descripon Display
Commands menu
*
Command Menu...
Display Inverter Fault History menu Inv Fault Hist...
10/2020 - ©Edwards Limited
Page 53M56635880_D
